High Power 750W Fume Extractor With 1000M3/H Air Flow For Laser
Cutting Welding Cleaning Machine
Features:
1, It is also a dust collector, bad smell remover, and fire proof;
We have a fire proof frame screen, bellows pocket to collect dust,
and PP HEPA filter and active carbon filters to remove bad gas.
2, It will alarm when the filters is out of service;
People can be easily know when to replace filters and any problem
happened if the machine is out of work.
3, The fume tube can be randomly rotate, and can be fix in any
position;
We using bamboo shape tube and 360°rotation support tube, to make
the machine position very flexible during work.
4, Our machine can maximize to use the filters;
We are using different layers filters to collect different size
level of pollution.
5, The fans material is special alloy, which can avoid corrosion;
The fans runs very stable and reliable, very big air flow;
Instructions:
| Model | FL-500II | FL-700II |
| Filter | 8 Layers | 9 Layers |
| Weight | 60kg | 70kg |
Dimensions (L*W*H) | 550*440*885mm | 550*440*1035mm |
| Air Flow | 750m³/h | 1000m³/h |
| Noise | <70dB | <75dB |
| Power | 450W | 700W |
| Voltage | AC 110-220V | AC 110-220V |
| Size of Filter (can be customized) |
Fireproof protection net | 415*335*25mm | 415*335*25mm |
| Primarry filter | 450*380*100mm | 450*380*100mm |
| PP Medium filter | 450*380*50mm | 450*380*50mm |
| Glass fiber filter | 450*380*100mm | 450*380*100mm |
Activated carbon filter | 450*380*50mm*2 | 450*380*50mm*2 |
Advantages:
1, Higher negative pressure then FL-500 model.
2, Imported motor from Germany and Longer machine life;
3, Improved the layers of filters into a intergrated filter, better
filter rate and higher efficiency;
4, Change the air inlet into the bottom of the machine and air
outlet in the top backside;
5, Assemble with big capacity dust collect bag, which can highly
save filter change cost;
FAQ
Q: What is your advantages?
A: All our models have explosion and fire proof function
certificate, and we have more than 8 years warrenty for the main
body and motor.
Q: Do you have agent in other country?
A: Yes, we have many sale agent and distributor all over the world,
and we have subsidiary in France and a big warehouse there.
Q: How long is needed for manufacture?
A: It always be about 3-7days, big quantity need to discuss.
Q: Why choose Fumego?
A: Lower using cost and longer machine life.
Q: Do you do OEM?
A: Yes
Q: What is the main parts of the machine?
A: Motor, control parts, Power source, Main body shell, tube, Smoke
cover and filters etc.
Q: Where is your factory?
A: We have 2 manufacture plant, in Shenzhen and Dongguan, have more
than 500 workers.
Q: What is the difference between fume extractor and air purifier?
A: The working princeple is closed, But application is different.
Fume extractor is more professional in clean fume, dust and bad
smells.
Product part picture:
